• | Image Sensor | : | 3K CMOS |
• | Signal System | : | PAL/NTSC |
• | Resolution | : | 2960 (H) × 1665 (V) |
• | Frame Rate | : | TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps AHD: 5 MP@20fps, 4 MP@25fps/30fps CVI: 4 MP@25fps/30fps CVBS: PAL/NTSC |
• | Min. Illumination | : | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
• | Shutter Time | : | PAL: 1/25 s to 1/50,000 s NTSC: 1/30 s to 1/50,000 s |
• | Lens | : | 2.8 mm, 3.6 mm fixed focal lens |
• | Field Of View | : | 2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122° 3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96° |
• | Lens Mount | : | M12 |
• | Light Alarm | : | Solid Light Alarm (White Light) |
• | Day & Night | : | 24/7 Color Imaging |
• | WDR (Wide Dynamic Range) | : | Digital WDR |
• | Angle Adjustment | : | Pan: 0° to 360°, Tilt: 0° to 75°, Rotation: 0° to 360° |
• | White Light | : | Auto/Off |
• | Image Mode | : | STD/HIGH-SAT/HIGHLIGHT |
• | AGC | : | Yes |
• | Day/Night Mode | : | Color |
• | White Balance | : | Auto/Outdoor/Global/Manual |
• | AE (Auto Exposure) Mode | : | BLC;HLC;Global;HLS;DWDR |
• | Noise Reduction | : | 2D DNR |
• | Language | : | English |
• | Function | : | Defective Pixel Correction;Sharpness;Mirror;Contrast;Brightness;Anti-Banding;Smart Light |
• | Video Output | : | Switchable TVI/AHD/CVI/CVBS |
• | Audio In | : | Built-in mic |
• | Operating Conditions | : | -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
• | Power Supply | : | 12 VDC ± 25% |
• | Consumption | : | Max. 2.5 W |
• | Protection Level | : | IP67 |
• | Material | : | Metal |
• | White Light Range | : | Up to 20 m |
• | Communication | : | HIKVISION-C |
• | Dimension | : | ? 85.1 mm × 77.62 mm (? 3.35 |
• | Weight | : | Approx. 328 g (0.72 lb.) |
