| • | Video Compression | : | H.265 Pro+/H.265 Pro/H.265/H.264+/H.264 |
| • | Encoding Resolution | : | When 1080p lite mode is not enabled: 4 MP lite/3 MP/1080p/720p/VGA/WD1/4CIF/CIF When 1080p Lite mode is enabled: 4 MP lite/3 MP/1080p lite/720p lite/VGA/WD1/4CIF/CIF |
| • | Frame Rate | : | Main stream: When 1080p Lite mode not enabled: For 4 MP stream access: 4 MP lite@15fps; 1080p lite/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N) For 3 MP stream access: 3 MP/1080p/720p/VGA/WD1/4CIF/CIF@15fps For 1080p stream access: 1080p/720p @15fps; VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) For 720p stream access: 720p/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) When 1080p Lite mode enabled: 4 MP lite/3 MP@15fps; 1080p lite/720p lite/VGA/WD1/4CIF/CIF@25fps (P)/30fps (N) Sub-strea |
| • | Video Bit Rate | : | 32 Kbps to 6 Mbps |
| • | Dual Stream | : | Support |
| • | Stream Type | : | Video, Video & Audio |
| • | Audio Compression | : | G.711u |
| • | Audio Bit Rate | : | 64 Kbps |
| • | IP Video Input | : | 2-ch (up to 6-ch) Up to 6 MP resolution Support H.265+/H.265/H.264+/H.264 IP cameras |
| • | Analog Video Input | : | 4-ch BNC interface (1.0 Vp-p, 75 ?), supporting coaxitron connection |
| • | AHD Input | : | 4 MP, 1080p25, 1080p30, 720p25, 720p30 |
| • | HDCVI Input | : | 1080p25, 1080p30, 720p25, 720p30 |
| • | CVBS Input | : | PAL/NTSC |
| • | Audio Input | : | 1-ch, RCA (2.0 Vp-p, 1 K?) |
| • | Audio Output | : | 1-ch, RCA (Linear, 1 K?) |
| • | Two-Way Audio | : | 1-ch, RCA (2.0 Vp-p, 1 K?) (using the first audio input) |
| • | Synchronous Playback | : | 4-ch |
| • | HDTVI Input | : | 4 MP, 3 MP, 1080p30, 1080p25, 720p60, 720p50, 720p30, 720p25 *: The 3 MP signal input is only available for channel 1 of DS-7204HQHI-K1/P, channel 1/2 of DS-7208HQHI-K2/P, and channel 1/2/3/4 of DS-7216HQHI-K2/P. |
| • | VGA/HDMI Output | : | 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz |
| • | PoC Camera Input | : | Support Hikvision PoC camera *: PoC access capability see Appendix. |
| • | CVBS Output | : | 1-ch, BNC (1.0 Vp-p, 75 ?),resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| • | Remote Connections | : | 32 |
| • | Network Protocols | : | TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF |
| • | Network Interface | : | 1, RJ45 10M/100M self-adaptive Ethernet interface |
| • | SATA | : | 1 SATA interface |
| • | Capacity | : | Up to 10 TB capacity for each disk |
| • | Alarm In/Out | : | N/A |
| • | USB Interface | : | 2 × USB 2.0 |
| • | Serial Interface | : | RS-485 (half-duplex) |
| • | Power Supply | : | 48 VDC |
| • | Working Temperature | : | -10 °C to +55 °C (+14 °F to +131 °F) |
| • | Working Humidity | : | 10% to 90% |
| • | Dimensions (W × D × H) | : | 315 × 242 × 45 mm (12.4 × 9.5 × 1.8 inch) |
| • | Weights (Without HDD) | : | ? 1.16 kg (2.6 lb) |
| • | Consumption (Without HDD) | : | ? 40 W |
