| • | Image Sensor | : | 1/2.7 inch CMOS |
| • | Effective Pixels | : | 2592 (H) × 1944 (V), 5MP |
| • | Scanning System | : | Progressive |
| • | Electronic Shutter Speed | : | PAL: 1/25s–1/100000s NTSC: 1/30s–1/100000s |
| • | S/N Ratio | : | >65dB |
| • | Minimum Illumination | : | 0.005Lux/F1.2, 0Lux White Light on |
| • | Fill Light (White Light) Distance | : | Distance up to 20 m (65.61 ft) |
| • | Fill Light On/Off Control | : | Auto; manual |
| • | Fill Light Number | : | 1 |
| • | Pan/Tilt/Rotation Range | : | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
| • | Lens Type | : | Fixed-focal |
| • | Mount Type | : | M12 |
| • | Focal Length | : | 2.8 mm; 3.6 mm |
| • | Max. Aperture | : | F1.2 |
| • | Field of View | : | 2.8 mm: 129° × 98° × 71° (diagonal × horizontal × vertical) 3.6 mm: 111° × 83° × 56° (diagonal × horizontal × vertical) |
| • | Iris Type | : | Fixed iris |
| • | Close Focus Distance | : | 2.8 mm: 1.6 m (5.25 ft) 3.6 mm: 2.1 m (6.89 ft) |
| • | Lens | : | 3.6 mm |
| • | Detect | : | 80.0 m (262.5 ft) |
| • | Observe | : | 32.0 m (105.0 ft) |
| • | Recognize | : | 16.0 m (52.5 ft) |
| • | Identify | : | 8.0 m (26.2 ft) |
| • | Frame Rate | : | CVI: PAL: 5M@20fps, 4M@25fps, 1080P@25fps; NTSC: 5M@20fps, 4M@30fps, 1080P@30fps AHD: PAL: 5M@20fps, 4M@25fps; NTSC: 5M@20fps, 4M@30fps TVI: PAL: 5M@20fps, 4M@25fps; NTSC: 5M@20fps, 4M@30fps CVBS: PAL: 960H; NTSC: 960H |
| • | Resolution | : | 5M (2592 × 1944) 4M (2560 × 1440) 1080P (1920 × 1080) 960H (704 × 576/704 × 480); |
| • | BLC | : | BLC/HLC/DWDR |
| • | WDR | : | DWDR |
| • | White Balance | : | Auto; manual |
| • | Gain Control | : | Auto; manual |
| • | Noise Reduction | : | 2D NR |
| • | Smart Light | : | Yes |
| • | Mirror | : | Off/On |
| • | Privacy Masking | : | Off/On (8 area, rectangle) |
| • | Video Output | : | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| • | Audio Input | : | Built-in mic (-A) |
| • | Power Supply | : | 12V ±30% DC |
| • | Power Consumption | : | Max 3.0W (12V DC, White Light on) |
| • | Operating Temperature | : | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
| • | Storage Temperature | : | -40°C to +60°C (-40°F to 140°F); <95% (non-condensation) |
| • | Protection Grade | : | IP67 |
| • | Casing | : | Inner core: metal + plastic Cover: plastic Pedestal: plastic |
| • | Camera Dimensions | : | ?97 mm × 85.8 mm (?3.82" × 3.38") |
| • | Net Weight | : | 0.22 Kg (0.49 lb) |
| • | Gross Weight | : | 0.28 Kg (0.62 lb) |
