| • | Image Sensor | : | 1/1.8 |
| • | Signal System | : | PAL/NTSC |
| • | Max. Resolution | : | 2960 (H) × 1665 (V) |
| • | Min. Illumination | : | 0.0003 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| • | Shutter Time | : | PAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s |
| • | Light Alarm | : | Solid Light Alarm (White Light) |
| • | Angle Adjustment | : | Pan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360° |
| • | Lens Type | : | 2.8 mm and 3.6 mm fixed focal lens |
| • | Focal Length & FOV | : | 2.8 mm, horizontal FOV: 112°, vertical FOV: 60°, diagonal FOV: 133° 3.6 mm, horizontal FOV: 95°, vertical FOV: 50°, diagonal FOV: 115° |
| • | Lens Mount | : | M16 |
| • | Frame Rate | : | 3K@20fps, 4MP@25fps/30fps, 1080p@25fps/30fps |
| • | Wide Dynamic Range (WDR) | : | ?130 dB |
| • | White Light | : | Auto/Off |
| • | Image Parameters Switch | : | STD/HIGH-SAT/HIGHLIGHT |
| • | AGC | : | Yes |
| • | Day/Night Mode | : | Color |
| • | White Balance | : | Auto/Outdoor/Global/Manual |
| • | Image Enhancement | : | WDR;Global;HLC;BLC;HLS |
| • | Privacy Mask | : | 4 programmable privacy masks |
| • | Noise Reduction | : | 3D DNR/2D DNR |
| • | Image Settings | : | Brightness;Contrast;Mirror;Smart Light;Anti-Banding |
| • | Video Output | : | 1 HD analog output |
| • | Motion Detection | : | 4 programmable motion areas |
| • | Language | : | English |
| • | Operating Condition | : | -40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing) |
| • | Power Supply | : | 12 VDC ± 25% *You are recommended to use one power adapter for one camera, and use 2-pin power supply for long-distance power supply. |
| • | Consumption | : | Max. 4 W |
| • | Material | : | Metal |
| • | White Light Range | : | Up to 20 m |
| • | Communication | : | HIKVISION-C |
| • | Dimension | : | 161.1 mm × 70 mm × 70 mm (6.34 |
| • | Weight | : | Approx. 400 g (0.88 lb.) |
| • | Protection | : | IP67 |
