| • | Image Sensor | : | 1/2.8 |
| • | Effective Pixels | : | 1920 (H) × 1080 (V) |
| • | ROM | : | 16 MB |
| • | RAM | : | 64 MB |
| • | Scanning System | : | Progressive |
| • | Electronic Shutter Speed | : | Auto/Manual 1/3 s–1/100000 s |
| • | Min. Illumination | : | 0.005 lux@F1.6 (Color, 30 IRE) 0.0005 lux@F1.6 (B/W, 30 IRE) 0 lux (Illuminator on) |
| • | S/N Ratio | : | > 56 dB |
| • | Illumination Distance | : | 2.8 mm: 10 m (32.81 ft) (Warm light) 3.6 mm: 15 m (49.21 ft) (Warm light) |
| • | Illuminator On/Off Control | : | Auto; Manual |
| • | Illuminator Number | : | 1 (Warm light) |
| • | Pan/Tilt/Rotation Range | : | Pan: 0°–360° Tilt: 0°–78° Rotation: 0°–360° |
| • | Lens Type | : | Fixed-focal |
| • | Mount Type | : | M12 |
| • | Focal Length | : | 2.8 mm 3.6 mm |
| • | Max. Aperture | : | 2.8 mm: F1.6 3.6 mm: F1.6 |
| • | Field of View | : | 2.8 mm: Pan 110° × Tilt 59° × Diagonal 132° 3.6 mm: Pan 91° × Tilt 48° × Diagonal 109° |
| • | Iris Type | : | Fixed |
| • | Close Focus Distance | : | 2.8 mm: 0.6 m (2.0 ft) 3.6 mm: 1.1 m (3.6 ft) |
| • | Lens | : | 2.8 mm 3.6 mm |
| • | Detect | : | 37.3 m (122.4 ft) 53.3 m (174.9 ft) |
| • | Observe | : | 14.9 m (48.9 ft) 21.3 m (69.9 ft) |
| • | Recognize | : | 7.5 m ( 24.6 ft) 10.7 m (35.1 ft) |
| • | Identify | : | 3.7 m (12.1 ft) 5.3 m (17.4 ft) |
| • | Video Compression | : | H.265; H.264; H.264H; H.264B; MJPEG |
| • | Smart Codec | : | Yes |
| • | Video Frame Rate | : | Main Stream: 1920 × 1080 (1 fps–25/30 fps) Sub stream: 704 × 576 (1 fps–25 fps) 704 × 480 (1 fps–30 fps) |
| • | Stream Capability | : | 2 streams |
| • | Resolution | : | 1080p (1920 × 1080) 1.3m (1280 × 960) 720p (1280 × 720) D1 (704 × 576/704 × 480) VGA (640× 480) CIF (352 × 288/352 × 240) |
| • | Bit Rate Control | : | CBR/VBR |
| • | Video Bit Rate | : | H.264: 32 Kbps–6144 Kbps H.265: 12 Kbps–6400 Kbps |
| • | Day/Night | : | Color/B/W |
| • | BLC | : | Yes |
| • | HLC | : | Yes |
| • | WDR | : | DWDR |
| • | White Balance | : | Auto/natural/street lamp/outdoor/manual/regional custom |
| • | Gain Control | : | Manual/Auto |
| • | Noise Reduction | : | 3D DNR |
| • | Motion Detection | : | OFF/ON (4 areas, rectangular) |
| • | Region of Interest(RoI) | : | Yes (4 areas) |
| • | Smart Light | : | Yes |
| • | Image Rotation | : | 0°/90°/180°/270° (Support 90°/270° with 1080p resolution.) |
| • | Mirror | : | Yes |
| • | Privacy Masking | : | 4 areas |
| • | Network | : | RJ-45 (10/100 Base-T) |
| • | Protocol | : | IPv4; IPV6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; SMTP; FTP; DHCP; DNS; NTP; DDNS ;Multicast |
| • | Interoperability | : | ONVIF (Profile S); CGI; P2P; Genetec |
| • | User/Host | : | 20 |
| • | Edge Storage | : | FTP; Dahua Cloud |
| • | Browser | : | IE Chrome Firefox |
| • | Management Software | : | Smart PSS; DSS; DMSS |
| • | Mobile Phone | : | IOS; Android |
| • | Power Supply | : | 12V DC/PoE (802.3af) |
| • | Power Consumption | : | <4.8 W |
| • | Operating Conditions | : | -40°C to +60°C (-40°F to +140°F)/less than ? 95% |
| • | Storage Temperature | : | -40°C to +60°C (-40°F to +140°F) |
| • | Ingress Protection | : | IP67 |
| • | Casing | : | Metal + plastic |
| • | Dimensions | : | 85.5 mm × ?109 mm (3.4" × ?4.3") |
| • | Net Weight | : | 0.24 kg (0.5 lb) |
| • | Gross Weight | : | 0.37 kg (0.8 lb) |
