| • | Pixel Distance | : | 4mm |
| • | Scan Cycle | : | 1/16 (16 Scan): Within 1 second, 16 pixels must be scanned |
| • | LED Ball Structure | : | 1R1G1B |
| • | LED Type | : | 3-in-1 Black |
| • | Dimensions 1 Panel Module | : | 256mm×128mm (Width:256mm, Height:128mm) |
| • | Module Resolution | : | 64×32dots |
| • | Total Pixels Per 1M² | : | 62500 dots/m² |
| • | Weight Of 1 LED Module Panel | : | 219g |
| • | View | : | H?120° V?120° (H: Horizontal, V: Vertical) |
| • | Maximum/Minimum Power | : | 519/208 w/m² |
| • | Light intensity | : | 1000cd/m² |
| • | Refresh Rate | : | ?1920Hz |
| • | Best Standing Distance From LED Display | : | 4m |
| • | Working Environment Temperature, Humidity | : | -10??+40?/ 10-80% no condensation |
| • | Storage Temperature, Humidity | : | -20??+60?/ 10-55% no condensation |
