| • | Resolution | : | 32(H) x 64(W) |
| • | Pitch | : | 5mm |
| • | Density | : | 40.000 pixels |
| • | LED Arrangement | : | SMD3528 |
| • | Driver Mode | : | 16s |
| • | Size | : | 320mm x 160mm |
| • | Mask | : | Pure Black mask-high contrast screen |
| • | Brightness | : | 1800cd |
| • | View Angle | : | 140 degree ( horizontal) 140degree(vertical) |
| • | View Distance | : | 4m - 240m |
| • | Gray Scale | : | 8bits input, correction with 16bits |
| • | Display Color | : | 16.7M |
| • | Brightness Adjustment | : | 100 levels |
| • | Operation Power | : | AC100-240V 50-60HZ Switch-able |
| • | Maxim Power Consumption | : | 1000 w |
| • | Average Power Consumption | : | 440 w |
| • | Correction Scale Level | : | 16bits |
| • | Frame Update Frequency | : | 60Hz |
| • | Screen Refresh Frequency | : | 2880Hz |
| • | Gamma Correction | : | -5.0mdash5.0 |
| • | Support Input | : | Composite Video, S-Video, DVI, HDMI., SDI |
| • | Control Distance | : | Ethernet cable 100m, optical fiber 5km |
| • | Support VGA Mode | : | 1024x768,1920 x1080 |
| • | Color Temperature | : | 5000-9300 adjustable |
| • | Brightness Correction | : | dot by dot, module by module,cabinet by cabinet |
| • | Operating Temp | : | -20?- +60? |
| • | Operating Humidity | : | 10-95% RH |
| • | Operating Life | : | 100,000 hours |
| • | MTBF | : | 5000 hours |
| • | Continuous Working Time | : | 72hours |
| • | Protection Level | : | IP25 |
| • | Out of Control Pixel Rate | : | 0.01% |
