| • | Pixel Pitch | : | 3mm |
| • | Pixel resolution | : | 64dots(W)*32 dots(H) |
| • | Brightness | : | 1200cd/m² @ white color |
| • | Gray Scale | : | 16.7M color (Synchronized) |
| • | Module Size | : | 192x192mm |
| • | Viewing Distance | : | 3-100M |
| • | Power Supply | : | AC220V/110V/50 Hz |
| • | Trouble Free Time | : | 10,000 hours |
| • | Environment Humidity | : | 10% ~ 95% |
| • | Refresh Rate | : | 1920Hz/s, could be adjusted |
| • | View Angle | : | H:140°, V:120° |
| • | Cabinet Size | : | 576x576mm |
| • | Drive Mode | : | 1/32 scan |
| • | Life Span | : | 100,000 hours |
| • | Working Temperature | : | -20°C + 65°C |
| • | Protection rating | : | IP41 front / IP54 back |
