| • | Power supply | : | 220V/50Hz;110V/60Hz |
| • | Motor power | : | 80W |
| • | Gate moving speed | : | 18~22 second per 90 (approx) |
| • | Max. single-leaf weight | : | 300Kg |
| • | Max. single-leaf length | : | 2.5M |
| • | Max. piston stroke | : | 34cm |
| • | Max. force | : | 1500N |
| • | Remote control distance | : | ?30m |
| • | Remote control mode | : | Single button mode |
| • | Storage battery (optional) | : | 24V or 12 VDC |
| • | Noise | : | ?58dB |
| • | Working duty | : | S2, 30min |
| • | Recording of up remote controls | : | 25 |
| • | Frequency | : | 433.92 MHz |
| • | Working temperature | : | -20°C - +70°C |
| • | Package weight | : | 17Kg |
