| • | Voltage | : | 12VDC±10% , Current 1.2A |
| • | Lock Relay | : | 12VDC/2A |
| • | Environmental temperature | : | Working:0°C-45°C Storage: -10°C-55°C |
| • | Relative Humidity | : | Working: 40%-90%RH Storage: -20%-90%RH |
| • | Card Capacity | : | 500,10000 |
| • | PIN Capacity | : | Public PIN: 1, Private PIN: 500,10000 |
| • | Internal Reader Frequency | : | EM-ID model: 125KHZ MIFARE®-IC model: 13.56MHZ |
| • | Proximity Card | : | ID model: EM or Compatible IC model: MiF or Compatible |
| • | Card Reading Distance | : | ID model: 5-15CM IC model: 3-5CM |
| • | Lock interface | : | Relay output or level output |
| • | Exit Button | : | One interface |
| • | Bell | : | One interface |
| • | Door Contact | : | One interface |
| • | Alarm Interface | : | One level output |
| • | External Reader | : | One weigand26 interface (only apply to certain models) |
