| • | Rated Voltage | : | 220V±10%/110V±10% |
| • | Rated Motor Power | : | 350W |
| • | Electric Motor | : | 220VAC/110VAC 120W |
| • | Output Torque(N.m) | : | 30N.m |
| • | Max Loading Weight | : | 800KG |
| • | Limit Switch Type | : | Magnetic/Spring |
| • | Output Speed | : | 50r/min±10% |
| • | Max. Pull Force | : | 1200N |
| • | Gear Modulus | : | M=4 |
| • | Open/Close Speed | : | 12m/min |
| • | Noise | : | ?55dB |
| • | Working Temperature | : | -20°C ~ +55°C |
| • | Duty Cycle | : | 80% |
